Overview

The standard panel is manufactured by hot-pressing colored PET (polyester) fibers into durable 9 mm thick panels available in a variety of colors. The unique properties of this non-woven material provide a uniform, non-directional texture with consistent color throughout the entire panel. Its durable edges enhance longevity while remaining easy to cut into virtually any shape. Currently, 12 standard stock colors are available.

The combination of design and performance makes Resonance Panels both visually appealing and highly functional. They effectively absorb indoor noise and manage the transmission of mid- and high-frequency sounds. These panels are ideal for applications requiring noise reduction, sound control, and echo suppression.

Resonance Panels are manufactured from polyester fibers combined with a flame-retardant additive, providing excellent fire resistance. Flame spread and smoke development test results are available in accordance with ASTM E84 (Class A or Class 1).

Resonance Panels are an ideal decorative acoustic solution. Made from 100% polyester fiber, they offer excellent sound absorption, fire resistance, insulation properties, moisture resistance, and mold resistance. They are easy to clean, cut, and install while remaining environmentally friendly. A wide range of patterns and colors is available to meet the unique design requirements of residential, commercial, and institutional projects.

Specifications

• Material: PET polyester fiber (50% recycled content)
• Panel Size: Up to 48″ × 96″ (4′ × 8′)
• Thickness: 9 mm
• Acoustic Performance: NRC up to 0.80 at 1000 Hz
• Fire Rating: Class A (ASTM E84)
• Colors: 9 standard colors (custom options available)

Materials

Durable 9 mm non-woven panels featuring consistent color throughout and excellent cut-to-shape flexibility, making them suitable for a wide range of architectural and decorative applications.
